IP65 waterproof LED Emergency Driver Battery Backup Kit with Battery Pack Aluminum Box kit

KVD188G:Waterproof Lighting Battery Pack Kits
Waterproof LED Emergency Battery Backup apply in Led constant current lighting luminaires’ normal lighting or emergency lighting mode, also can be only for emergency lighting purpose.

Emergency lighting solutions provided “charging”, and “discharging” functions, and use intelligent IC controlling circuits, according to be high exchange efficiency and smaller battery capacity.

Internal Li-ion battery, compatible with dimming or non-dimming led luminaire, external installation, emergency supply will be standing and charging by when AC grid electricity supply in normal, will be going to self-maintenance when fully charged, according to longer the battery’s lifespan

The emergency driver will be back up the lighting luminaires within 1 second when AC grid electricity stopped, to be sure the light can be working for 1 to 3hrs normally.

Each LED lighting emergency module is consist of an emergency driver and battery power, and sometimes there is an extra box container outside. In this product, it is an aluminum IP65 waterproof box.

The IP65 waterproof box is compatible with any other emergency ballast and battery pack, so you can freely choose the emergency power and duration time.

Categories: , , , , , , , ,

This waterproof LED Emergency Driver kit Model is KVD188G， the Aluminum shell material is lighter and saves transportation costs. Is the energy-saving emergency solution for an LED lighting fixture, we have an 11.1v battery pack. The KVD188G support LED light powered at 20w-200w, lighting Emergency application.

The waterproof LED Emergency Battery Backup fits for most Industrial lights,especially UFO Highbay light,Linear Highbay light,Tunnel light and Explosion-proof light.

Emergency LED Driver Battery Backup Kits specifications:
1. Emergency Power: 10W 20W  30W  40W
2. Lighting fixture Power: 20w- 200w
3. Conversion Efficiency: ≥95%
4. Battery Type: 1 pcs Li-ion battery
5. Emergency runtime :1.5 hours to 3 hours
6. Input Voltage: AC100-277V
7. Output Voltage: DC100V-260V
8. Charging Time: 24 hours
9. Product Weight: 2000mAh Li-ion battery-400g   4000mAh Li-ion battery-500g
10. Working Lifetime(Hour)30000
11. 3 years warranty.
12. Best quality and factory price.
13. Obtain CE  ROHS  UKCA

Emergency Ballast  Advantages:
Lighting emergency products
Obtained CE ,UKCA certifications
Comply CE ,UKCA ordinances
Compatible with all brands of constant current LED drivers
Constant power output
High voltage output
Low energy consumption complies with CEC standards
Charging and dis-charging protection function and over heat temp. protection
Battery zero power consumption under static state
Mock-up electricity pause emergency testing function
Can be power off under emergency status
Indication light: city grid electricity,charging, fault
Seasonal self detect function
Protection functions: over voltage, short circuit, over load and open circuit
Metal housing, comply EMC, FCC and C tick ordinances
IP grade: IP65
We obtained international air and sea transportation documents



Working Environment Attention

Working & storage temperature: 0℃–+50℃（Standard temperature 20℃-35℃ is best ）
To ensure a longer lifetime, an LED emergency battery is needed to be charged and discharged every 3 months.
If stored longer than 3 months in the warehouse, an emergency battery is needed to be charged and discharged every 3 months.
Our emergency batteries can be charged/discharged 500 cycles if used in the right way.
Please make sure the wire connection is correct before switching on for long time usage.
